Loft Semi Wall Faced Toilet

372125P, 372125S, 372125SE

The Loft Semi Wall Faced suite offers the best of both worlds. The elegant sculptural lines echo those of a full wall faced suite bringing its contemporary good looks to any bathroom.

The reart access to the pan ensures easier installation and makes future servicing easy and more cost effective, by providing direct access to the pan. In addition this also allows the waste pipe to be connected to either the left or right hand side. Refer to image

Streamlined beauty combined with practical design

  • Soft close (Quick Release) seat with stainless steel hinges and top fix for easy access
  • Quality R&T/WDI flush valves
  • Universal inlet: Bottom inlet (Left or Right) or Top Inlet
  • EVO water efficient system for 4.5/3 litre dual flush
  • WELS 4 star rated
  • Box rim direct flush pan for better flush action

Product Codes:

S pan suite:
70 - 170mm Set Out Universal Inlet 372125S
150 - 230mm Set Out Universal Inlet 372125SE

P pan suite:
Universal Inlet 372125P

Dimensions
Pan Seat Height 460mm, Pan Depth 680mm, Set Out 70-170mm, Set Out Extended 150-230mm,
Quick View Line Drawing

$608.28 incl GST
Print
DOWNLOADS
Loft 372125 Line Drawing
(663 kb)
Loft 372125 FRONT dwg
(140 kb)
Loft 372125 FRONT dxf
(125 kb)
Loft 372125 SIDE dwg
(119 kb)
Loft 372125 SIDE dxf
(43 kb)
Loft 372125 TOP dwg
(115 kb)
Loft 372125 TOP dxf
(38 kb)
Loft 372125 BACK dwg
(123 kb)
Loft 372125 BACK dxf
(65 kb)
Loft 372125 3ds
(631 kb)
Loft 372125 dae
(3.29 mb)
Loft 372125 obj
(3.24 mb)
Loft 372125 skp
(8.63 mb)
Loft 372125 ifc
(3.7 mb)
